2 Description of the operating controls and indicators

Item Control or indicator EMC/EMB Function

1 Collision protection button t The truck moves away from the

operator.

2 Controller t Controls the direction and speed

of travel.

3 Button “Lift load lifting device” t For lifting the load lifting device.

4 Button “Lower load lifting

device”

t For lowering the load lifting

device.

5 Button “Horn” t Triggers an acoustic signal.

6 Weighing system o Indicates the weight of the load

that has been picked up.

7 LED “Charging state” t Indicates the charging state of

the battery (see chapter D,

section 3).

8 Integrated charger

(incl. safety cut-out)

t The battery is charged when the

mains plug is plugged into an

electric outlet.

9 Emergency stop plug t The circuit is interrupted, all

electrical functions are switched

off.

10 Key switch t For switching the control current

on and off. Removing the key

prevents the truck from being

switched on by unauthorised

persons.

11 Battery discharge monitor t Indicates the remaining capacity

of the battery (see chapter D,

section 5).

t = Standard equipment o = Optional equipment
