Table 6: T1/E1 Port Features (continued)
DescriptionFeature
Category 5 shielded twisted pairCable
100-ohm RJ-48 connectorConnector
0/0/0 through 0/0/15Port numbering (hardware)
T1 framing (default): ct1-0/0/0 through ct1-0/0/15
E1 framing: ce1-0/0/0 through ce1-0/0/15
Port numbering (software)
Gigabit Ethernet RJ-45 Ports
The front panel of the ACX2000 router has six Gigabit Ethernet RJ-45 ports, and the ACX2100 router has
eight Gigabit Ethernet RJ-45 ports. Table 7 on page 52 describes the ports in more detail.
Table 7: RJ-45 Port Features
DescriptionFeature
•
10BASE-T Copper
•
100BASE-T
•
1000BASE-T
Supported standards
Category 5Cable
RJ-45Connector
•
ACX2000: 0/1/0 through 0/1/2 and 0/1/4 through 0/1/6
•
ACX2100: 1/0/0 through 1/0/3 and 1/1/0 through 1/1/3
Port numbering (hardware)
•
ACX2000: ge-0/1/0 through ge-0/1/2 and ge-0/1/4 through ge-0/1/6
•
ACX2100: ge-1/0/0 through ge-1/0/3 and ge-1/1/0 through ge-1/1/3
Port numbering (software)
PoE Ports
Each ACX2000 router has two PoE Gigabit Ethernet ports. These ports allow you to plug in devices that
require both network connectivity and electric power such as IP phones, wireless access points, and security
cameras. Table 8 on page 53 describes the ports in more detail.
52
