NOTE: We recommend that you use a dedicated customer site circuit breaker rated for
2 A (100 VAC) or 1 A (240 VAC), or as required by local code. Doing so enables you to operate
the router in any configuration without upgrading the power infrastructure.
SEE ALSO
Connecting AC Power Cords to the ACX2100 Router | 104
ACX2100 AC Power Cord Specifications
Each AC power supply has a single AC appliance inlet that requires a dedicated AC power feed. Most sites
distribute power through a main conduit that leads to frame-mounted power distribution panels, one of
which can be located at the top of the rack that houses the router. An AC power cord connects each power
supply to the power distribution panel.
You can order detachable AC power cords, each approximately 8 ft (2.5 m) long that supply AC power to
the router. The C15 appliance coupler at the female end of the cord, as described by International
Electrotechnical Commission (IEC) standard 60320, inserts into the AC appliance inlet coupler. The plug
at the male end of the power cord fits into the power source receptacle that is standard for your geographic
location.
Table 20 on page 63 provides specifications on the AC power cord provided for each country or region.
Table 20: AC Power Cord Specifications
Design StandardPlug TypeElectrical SpecificationModel NumberCountry
AS/NZZS 3112-2000SAA/3250 VAC, 10 A, 50 HzCBL-GP-C15-AUAustralia
GB2099, GB1002PRC/3250 VAC, 10 A, 50 HzCBL-GP-C15-CHChina
CEE (7) VIIVIIG250 VAC, 10 A, 50 HzCBL-GP-C15-EUEurope (except Italy,
Switzerland, and
United Kingdom)
CEI 23–16I/3G250 VAC, 10 A, 50 HzCBL-GP-C15-ITItaly
JIS 8303498GJ125 VAC, 15 A, 50 Hz or 60
Hz
CBL-GP-C15-JPJapan
63
