Juniper ACX2100 - Installing the ACX2000 or ACX2100 Router in the Rack

Figure 18: Installing the Mounting Brackets to the Front of the ACX2000 or ACX2100 Router
g006405
Figure 19: Installing the Mounting Brackets to the Rear of the ACX2000 or ACX2100 Router
g006406
Installing the ACX2000 or ACX2100 Router in the Rack
NOTE: The router can be installed horizontally in a rack or cabinet. For additional installation
options, contact JTAC.
97
