7. Connect each power supply to the power sources. Secure power source cables to the power
supplies by screwing the ring lugs aached to the cables to the appropriate terminals by using the
screw from the terminals (see Figure 52 on page 119and Figure 53 on page 120 ).
The QFX5200-32C is designed to operate with a DC power supply that has a single, non-
redundant, feed input. For source redundancy, two DC power supplies must be installed in
QFX5200-32C; connect source (A) to one power supply and connect source (B) to the second
power supply. This conguraon provides the commonly deployed A/B feed redundancy for the
system.
The terminal block of the power supply has four terminals labeled V+, V+, V–, and V– for
connecng DC power source cables labeled posive (+) and negave (–). The V+ terminals are
shunted internally together, as are the V- terminals.
CAUTION: The connecon between each power source and power supply must
include a circuit breaker.
Do not connect two sources to a single power supply because doing so can
potenally cause circulang current in feed wires whenever there is any dierence
in the voltage of the two sources.
a. Secure the ring lug of the posive (+) DC power source cable to the V+ terminal on the DC
power supply.
b. Secure the ring lug of the negave (–) DC power source cable to the V– terminal on the DC
power supply.
118
