Table 37: Console Port Connector Pinouts for the QFX Series
Pin Signal Descripon
3 TxD Output Transmit data
4 Signal Ground Signal ground
5 Signal Ground Signal ground
6 RxD Input Receive data
RJ-45 Port, SFP Port, SFP+ Port, QSFP+ Port, and QSFP28 Port
Connector Pinout Informaon
The tables in this topic describe the connector pinout informaon for the RJ-45, QSFP+, QSFP28, SFP+,
and SFP ports.
Table 38 on page 86—10/100/1000BASE-T Ethernet network port connector pinout informaon
Table 39 on page 87—SFP network port connector pinout informaon
Table 40 on page 89—SFP+ network port connector pinout informaon
Table 41 on page 90—QSFP+ and QSFP28 network module ports connector pinout informaon
Table 38: 10/100/1000BASE-T Ethernet Network Port Connector Pinout
Informaon
Pin Signal Descripon
1 TRP1+ Transmit/receive data pair 1
Negave Vport (in PoE models)
2 TRP1- Transmit/receive data pair 1
Negave Vport (in PoE models)
86
