Table 32: QSFP+ and QSFP28 Opcal Module Receptacle Pinouts (Connued)
Fiber Signal
8 Unused
9 Rx3 (Receive)
10 Rx2 (Receive)
11 Rx1 (Receive)
12 Rx0 (Receive)
Table 33: QSFP+ MPO Fiber-Opc Crossover Cable Pinouts
Pin Pin
1 12
2 11
3 10
4 9
5 8
6 7
7 6
8 5
9 4
78
