About This Guide
This guide contains information that you need to install and configure the SRX5400 Services Gateway
quickly. For complete installation instructions, see the SRX5400 Services Gateway hardware documentation
at www.juniper.net/documentation/.
WARNING: This guide contains a summary of safety warnings in “Safety Warnings” on
page 29. For a complete list of warnings for this device, including translations, see the
SRX5400 Services Gateway hardware documentation at www.juniper.net/documentation/.
The SRX5400 Services Gateway is a high-performance, highly scalable, carrier-class security device with
multi-processor architecture.
The SRX5400 Services Gateway is 5 rack units (U) tall. Five of these devices can be stacked in a single
floor-to-ceiling rack, for increased port density per unit of floor space.
The services gateway provides four slots that you can populate with one Switch Control Board (SCB) and
up to three additional cards of the following types:
•
Services Processing Cards (SPCs) provide the processing capacity to run integrated services such as
firewall, IPsec, and IDP.
•
Modular Port Concentrators (MPCs) and the Modular Interface Cards (MICs) that install in them provide
Ethernet interfaces that connect the services gateway to your data network.
NOTE: The SRX5400 Services Gateway supports the SRX5K-SPC-4-15-320 SPC only. It does
not support the SRX5K-SPC-2-10-40 SPC.
By installing different combinations of MPCs and SPCs, you can tailor both the number of ports and the
maximum services processing capacity to suit your network. Table 1 on page 3 describes the possible
system configurations for the SRX5400 Services Gateway.
Table 1: Possible System Configurations
MaximumMinimumComponent
21SPC
21MPC
11SCB
3
