Step 5: Connect External Devices and Network Cables
IN THIS SECTION
Connect to a Network for Out-of-Band Management | 16
Connect a Management Console | 16
Connect the Network Cables | 17
To connect external devices and network cables:
Connect to a Network for Out-of-Band Management
1. Turn off the power to the management device.
2. Plug one end of the RJ-45 Ethernet cable into the appropriate ETHERNET port on the services gateway
Routing Engine.
3. Plug the other end of the cable into the network device.
Connect a Management Console
1. Plug one end of the RJ-45 Ethernet cable into the CONSOLE or AUX port on the services gateway
Routing Engine.
2. Plug the female DB-9 end into the device’s serial port.
