5. To install the chassis in an open-frame rack, install a mounting screw into each of the open mounting
holes aligned with the rack, starting from the bottom.
6. Visually inspect the alignment of the chassis. If the chassis is installed properly in the rack, all the
mounting screws on one side of the rack should be aligned with the mounting screws on the opposite
side and the chassis should be level.
Reinstall Components
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
one of the ESD points on the chassis. For more information about ESD, see the SRX5400 Services
Gateway hardware documentation at www.juniper.net/documentation/.
2. Slide each component into the chassis evenly so that it does not become stuck or damaged.
3. Tighten the captive screws or lock any levers for each component installed.
NOTE: Make sure that all empty slots are covered with blank panels before you operate the services
gateway.
Proceed to “Step 4: Connect the Grounding Cable” on page 14.
Step 4: Connect the Grounding Cable
WARNING: To meet safety and electromagnetic interference (EMI) requirements and
to ensure proper operation, you must properly ground the services gateway chassis
before connecting power.
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect the strap to
an approved site ESD grounding point. See the instructions for your site.
2. Connect the grounding cable to a proper earth ground.
14
