7.12.4 TRACK SHOE BOLTS
Tighten the track shoe bolts after the first 100 hours of operation and thereafter once a
month. The track shoes must be fastened within the exact torque values shown in the
following table.
Machine type Mounting bolt
Torque values
Nm
lb-ft
With
lubricant
Without
lubricant
PM 16, 20 5/8” – 18 UNF
304 - 358
220 - 259
365 - 430
264 - 311
PM 25 3/4” – 16 UNF
526 - 620
380 - 448
631 - 744
457 - 538
PM 18, 23, 26 M 20 x 1.5
622 - 731
450 - 529
747 - 877
540 - 635
PM 28, 30, 40 M 24 x 1.5
1095 - 1288
792 - 932
1314 - 1546
950 - 1118
