JUNTTAN PM 20L - Controls on the Left Console

JUNTTAN Controls section
54
5.5 CONTROLS ON THE LEFT CONSOLE
LATERAL INCLINATION LEVER
Diagonally The leader is inclined (raked) to
forward the respective side (cylinder is pushed out)
Diagonally The leader is inclined (raked) to
backward the opposite side (cylinder is pulled in)
Forward The leader is inclined (raked) forward
(both cylinders are pushed out)
Backward The leader is inclined (raked) backward
(both cylinders are pulled in)
SWING LEVER
Forward Horizontal slide out
Backward Horizontal slide in
Left Swings machinery deck to the left
Right Swings machinery deck to the right
Diagonal Combinations
Top switch Pile arms open
Pile arms close
