JUNTTAN PM 20L - Hydraulic Filters; Electrical Components

JUNTTAN Specifications section
16
Horizontal slide cylinder
- type: double acting
- stroke: 1500 mm
Track width adjustment cylinders (2)
- type: double acting
- stroke: 1000 mm
- load holding valve installed
Pile arm cylinders (2)
- type: double acting
- stroke: 265 mm
- load holding valve installed
Stabilizer cylinder (2)
- type: double acting
- stroke: 1150 mm
- load holding valve installed
3.7 HYDRAULIC FILTERS
See attached schematic diagram of hydraulic circuits of the machine and of the various
items of equipment.
Piping: Steel hydraulic pipes and reinforced hydraulic hoses
Cooling system: Hydraulic oil coolers with fans
Filters
- pressure: FF7006.Q020.BS35.GL20, cartridge FC7006.Q020.BK (3)
- return: FF1097.Q010.BA16.SX32-M, cartridge FC1097.Q010.BS (2)
- leak oil: FF1003.Q005.BA16.GT12, element FC1003.Q005.BS (1)
3.8 ELECTRICAL COMPONENTS
Battery type and capacity: 2 * 12 V 180 Ah
Details of electrical controls and equipment: 24 VDC with fuses and relays
See attached schematic diagram of electric circuits of the machine and of the various
items of equipment.
