JUNTTAN Specifications section
14
3.3 ENGINE
Name of manufacturer: Cummins
Type of engine: Turbo-charged diesel
Model of engine: QSB6.7 Tier3
Serial number of engine: 21791780
Number of cylinders: 6 (in line)
Bore: 104 mm
Stroke: 132 mm
Rated power: 176 kW/240 hp at 2000 rpm
Type of fuel filter: FS-19732, FF-5485
Type of oil filter: LF-3970
Type of air filters: P77-7414
P77-7409
Type of cooling system: By liquid
3.4 HYDRAULIC PUMPS
Main pump
- model: A8VO80LA1KH3
- type: adjustable double axial pump with
summing power regulation
- rated capacity/rotation speed: max. 2 * 170 l/min at 2200 rpm
- service operating pressure: max. 350 bar
Secondary pump
- model: A2FO45
- type: fixed displacement pump
- rated capacity/rotation speed: max. 98 l/min at 2200 rpm
- service operating pressure: max. 350 bar
Auxiliary pump
- model: 0510665354
- type: double fixed displacement gear pump
- rated capacity/rotation speed: 22+32 l/min at 2000 rpm
