JUNTTAN Specifications section
13
3. SPECIFICATIONS SECTION
3.1 GENERAL IDENTIFICATION
Trade mark of the machine: Junttan PM 20L
Type of the machine: Piling rig for impact driving
Model: PM 20L
Serial number: 1461
Name and address of manufacturer: Junttan Oy
PL 1702
70701 KUOPIO
FINLAND
Year of manufacture: 2008
3.2 GENERAL DIMENSIONS
Maximum height: 23 450 mm
Maximum width in working: 4 350 mm
Maximum length: 9 230 mm
Maximum pile length (with hammer HHK 3/4AL): 18 000 mm
3.2.1 TRANSPORT DIMENSIONS
Length (leader turned): 19 450 mm
Width: 3 350 mm
Height: 3 300 mm
Height (with hammer HHK 3/4AL): 3 700 mm
3.2.2 CRAWLER
Dimension between sprocket axis and the idler axis: 3 920 mm
Total length of crawler base: 4 760 mm
Transverse width over tracks in transport: 3 350 mm
Transverse width over tracks in full working width: 4 350 mm
Size of track shoes: 900 mm
Number of track shoes: 2*61
Number of rollers upper run: -
Number of rollers bottom run: 12
