JUNTTAN PM 20L - Winches; Safety Devices

JUNTTAN Specifications section
17
3.9 WINCHES
Pile winch (left)
- model: BB7
- lifting capacity: 8 ton
- ropeline specification: Ø22 mm-70 m, 35*7 Compacted 2160 N/mm
2
Hammer winch (right)
- model: BB7
- lifting capacity: 10 ton
- ropeline specification: Ø25 mm-52 m, 6x36-IWRC 1770 N/mm
2
3.10 SAFETY DEVICES
AUDIBLE ALARMS
- hammer top position on the leader
- pile winch top position on the leader
- drive
- swing
- pressure of the forward inclination cylinder too high
- by-pass switch of the winches top limits
VISUAL ALARMS
- position of the safety lever
- leader inclinometer
- forward inclination cylinder released
- base carrier inclination meters
- winches top position
- winches brakes
- filter blockage
- backward inclination >30°
- hydraulic oil level
- horizontal slide and lateral inclination cylinders in
- leader lift device fully up
- leader against leader lift device
- air filter
- engine oil pressure
- engine temperature
- charge indicator
- fuel level
- piling switch position
- engine indicator lamps
