Jupiter AX411 Access Point User Manual

Table 25: RJ-45 Connector Pinouts for Access Point Console Port
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Related
Documentation
• Interface Cable and Wire Specifications for the AX411 Access Point on page 101
• RJ-45 Connector Pinouts for the AX411 Access Point Ethernet Port on page 101
103Copyright © 2012, Juniper Networks, Inc.
Appendix D: AX411 Access Point Interface Cable Specifications and Connector Pinouts
