You can connect and use up to two access points on the services gateway without
obtaining access point licenses. To use more than two access points, you must obtain
an additional access point license (SKU AX411-2) and install it on the services gateway.
You obtain access point licenses from your Juniper Networks representative or reseller.
Table 3 on page 4 shows the maximum number of access points supported for each
applicable services gateway type.
Table 3: Maximum Number of Access Points per Services Gateway Type
Maximum Number of AX411 Access Points SupportedServices Gateway Type
4SRX210
2SRX220
4SRX240
4SRX650
NOTE: If you have previously deployed a greater number of access points
per services gateway than specified in Table 3 on page 4, we recommend
thatwhen practical youreduce the numberof accesspointstothose specified.
If you want to deploy more than four access points, we recommend that you
use Juniper Networks WLA SeriesWireless LAN accesspoints and WLC Series
Wireless LAN Controllers.
Related
Documentation
Deploying WLANs with AX411 Access Points on page 4•
• AX411 Access Point Physical Specifications on page 6
• AX411 Access Point Front Panel and LEDs on page 9
• AX411 Access Point Rear Panel on page 10
Deploying WLANs with AX411 Access Points
To deploy a wireless network with AX411 Access Points, you install one or more access
points throughout your site and connect them to Ethernet ports on the services gateway
that manages the access points. You can provide power to the access points using Power
over Ethernet (PoE) by connecting them to services gateway ports that have PoE
capability. You can also provide power to the access points using either optional external
power supplies or PoE adapters.
You can connect the access points either directly to the SRX Series device or to a Layer
2 switch that is connected to the SRX Series device.
Figure 2 on page 5 shows a typical WLAN deployment in which four AX411 Access Points
are connected directly to an SRX210 Services Gateway.
