Figure 2: Typical WLAN Deployment
Inte rnet
g033104
Figure 3 on page 5 shows a WLAN deployment in which four AX411 Access Points are
connected to an EX4200 Ethernet switch that is connected to an SRX210 Services
Gateway.
Figure 3: WLAN Deployment Using an Ethernet Switch
Inte rnet
g033107
