(No.52114)3-25
DAF P.W. BOARD ASS'Y (SGJ-2502A-M2)
CRT SOCKET P.W. BOARD ASS'Y (SGJ-3503A-M2)
L704 QQL244K-220Z COIL 22uH K
L705 QQL244K-220Z COIL 22uH K
L931 QQL26AK-470Z COIL 47uH K
L933 QQL26AK-470Z COIL 47uH K
L937 QQL26AK-470Z COIL 47uH K
L940 QQR0582-001Z FERRITE BEADS
T111 QQR0907-001 IFT
T501 CE42034-002 HOR DRIVE TRANS
T921 QQS0225-001 SW TRANSF
T951 QQT0372-001 POWER TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
CF161 QAX0642-001Z C FILTER 4.500MHz
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN004 QGA2501C5-07Z CONNECTOR W-B (1-7)
CN005 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN007 QGA2501C5-06Z CONNECTOR W-B (1-6)
CN008 WJM0212-003A E-SI C WIRE C-F
CN009 QJB003-033626 SIN ID C-B WIRE
CN00C QGA2501F1-06 CONNECTOR W-B (1-6)
CN00K QGA2501C5-05Z CONNECTOR W-B (1-5)
CN00Q QGA2501C5-03Z CONNECTOR W-B (1-3)
CN0CP CE41507-001P LV CONNECTOR
CN0E1 CE41507-001P LV CONNECTOR
CN0E3 CE41507-001P LV CONNECTOR
CN0HV QGZ5004C1-06 CONNECTOR (1-6)
CN0S1 QGA2501C5-05Z CONNECTOR W-B (1-5)
CN0SS QGA2501C5-04Z CONNECTOR W-B (1-4)
CP932 ICP-N70-T IC PROTECTOR 2.5A
CP933 ICP-N70-T IC PROTECTOR 2.5A
CP936 ICP-N70-T IC PROTECTOR 2.5A
F901 QMF51N1-5R0-J5 FUSE 5A AC125V
F905 QMFZ049-5R0Z-E FUSE 5A 125V
FC901 CEMG002-001Z FUSE CLIP
FC902 CEMG002-001Z FUSE CLIP
FR525 QRZ9017-4R7 FUSI RESISTOR 4.7
Ω
1/4W J
FR527 QRZ9011-470 FUSI RESISTOR 47
Ω
1/2W J
HS001 LC32313-001A HEAT SINK/AL-F/
HS002 LC31948-001A HEAT SINK/AL-F/
HS003 LC31677-001A HEAT SINK/AL-F/
HS004 CEHE015-001WU HEAT SINK
HS005 CM42862-00G-H HEAT SINK ASSY
HS007 CEHT11B-002QS HEAT SINK
J601 QNN0349-002 PIN JACK COMP IN
J810 QNS0001-001 3.5 JACK AV COMPLINK III
K401 QQR0621-002Z FERRITE BEADS
K912 QQR0582-001Z FERRITE BEADS
K916 QQR0582-001Z FERRITE BEADS
K917 QQR0582-001Z FERRITE BEADS
K918 QQR0582-001Z FERRITE BEADS
K920 QQR0872-002 FERRITE BEADS
K931 QQR0582-001Z FERRITE BEADS
K932 QQR0582-001Z FERRITE BEADS
K933 QQR0582-001Z FERRITE BEADS
K935 QQR0582-001Z FERRITE BEADS
K937 QQR0582-001Z FERRITE BEADS
LC601 QQR1199-001 EMI FILTER
LC602 QQR1199-001 EMI FILTER
LC603 QQR1199-001 EMI FILTER
LF901 QQR1159-001 LINE FILTER
LF902 QQR0527-004 LINE FILTER
RY951 QSK0085-001 RELAY
SF101 QAX0723-001 SAW FILTER
TH901 QAD0132-3R0 P THERMISTOR 3
Ω
TU001 QAU0274-001 TUNER
VA901 ERZV10V621CS ZNR
X701 QAX0717-001Z CRYSTAL 8.000MHz
Ref No. Part No. Part Name Description Local
Q2751 2SD601A/QR/-X TRANSISTOR
Q2752 2SD601A/QR/-X TRANSISTOR
Q2753 2SC4632 POW TRANSISTOR
D2761 ES1F-LFG2 SI DIODE
D2762 ES1F-LFG2 SI DIODE
D2771 MTZJ33A-T2 Z DIODE
C2701 QFV71HJ-104Z MF CAPACITOR 0.1uF 50V J
C2751 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C2752 QETN1EM-476Z E CAPACITOR 47uF 25V M
Ref No. Part No. Part Name Description Local
C2753 QFZ0122-103 MPP CAPACITOR 0.01uF 1.8kV H
C2761 QFZ0122-682 MPP CAPACITOR 6800pF 1.8kV H
C2771 QETN1HM-106Z E CAPACITOR 10uF 50V M
R2701 QRG01GJ-220 OMF RESISTOR 22
Ω
1W J
R2702 QRE121J-123Y C RESISTOR 12k
Ω
1/2W J
R2703 QRZ0056-103Z COMP RESISTOR 10k
Ω
1/2W K
R2751 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R2752 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R2753 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R2754 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R2755 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R2756 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R2757 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R2758 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R2761 QRE121J-184Y C RESISTOR 180k
Ω
1/2W J
R2762 QRE121J-184Y C RESISTOR 180k
Ω
1/2W J
R2763 QRE121J-184Y C RESISTOR 180k
Ω
1/2W J
R2764 QRE121J-184Y C RESISTOR 180k
Ω
1/2W J
R2765 QRE121J-184Y C RESISTOR 180k
Ω
1/2W J
R2771 QRL039J-223 OMF RESISTOR 22k
Ω
3W J
L2701 QQLZ028-272 COIL 2.7mH
T2701 QQR1153-001 DAF TRANSF
CN200K WJA0028-001A E-S ID WIRE
CN200Q WJA0026-001A E-S ID WIRE
CN20CP QUB573-26A6FX SIN TWIST WIRE
CN2DAF CE41507-001P LV CONNECTOR
Ref No. Part No. Part Name Description Local
Q3103 2SA933AS/QR/-T TRANSISTOR
Q3105 2SC1740S/QR/-T TRANSISTOR
Q3106 2SA933AS/QR/-T TRANSISTOR
Q3107 2SA1964/DE/ POW TRANSISTOR
Q3108 2SC5248/DE/ POW TRANSISTOR
Q3109 2SC1740S/QR/-T TRANSISTOR
Q3151 2SC1740S/QR/-T TRANSISTOR
Q3152 2SA933AS/QR/-T TRANSISTOR
Q3301 2SC5083/L-P/-T TRANSISTOR
Q3302 2SC5083/L-P/-T TRANSISTOR
Q3303 2SC5083/L-P/-T TRANSISTOR
Q3304 2SC5147/CDE/F43 POW TRANSISTOR
Q3305 2SC5147/CDE/F43 POW TRANSISTOR
Q3306 2SC5147/CDE/F43 POW TRANSISTOR
Q3351 2SA933AS/QR/-T TRANSISTOR
D3101 1SS133-T2 DIODE
D3105 RH1S-T3 SI DIODE
D3106 RH1S-T3 SI DIODE
D3301 1SS133-T2 DIODE
D3302 1SS133-T2 DIODE
D3303 1SS133-T2 DIODE
D3304 1SS82-T2 SI DIODE
D3305 1SS82-T2 SI DIODE
D3306 1SS82-T2 SI DIODE
D3311 MTZJ3.6B-T2 Z DIODE
D3312 1SS133-T2 DIODE
D3313 MTZJ4.3A-T2 Z DIODE
D3314 1SS133-T2 DIODE
D3331 1SS133-T2 DIODE
D3351 1SS133-T2 DIODE
D3352 1SS133-T2 DIODE
D3353 1SS133-T2 DIODE
D3354 1SS133-T2 DIODE
D3361 RM2C-LFA1 SI DIODE
C3101 QETN1HM-106Z E CAPACITOR 10uF 50V M
C3109 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3110 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3111 NDC31HJ-221X C CAPACITOR 220pF 50V J
C3113 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3114 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3115 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3117 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3118 QETN0JM-107Z E CAPACITOR 100uF 6.3V M
C3119 QETN1AM-107Z E CAPACITOR 100uF 10V M
C3120 QETN1AM-337Z E CAPACITOR 330uF 10V M
C3121 QCS32HJ-151Z C CAPACITOR 150pF 500V J
C3122 NDC31HJ-5R0X C CAPACITOR 5pF 50V J
C3125 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Ref No. Part No. Part Name Description Local
