(No.52114)3-11
FRONT CONTROL P.W. BOARD ASS'Y
(SGJ-6501A-M2)
LED & POWER SW P.W. BOARD ASS'Y
(SGJ-7502A-M2)
R5034 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R5151 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5152 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5153 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5154 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5155 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5157 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5159 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5210 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5211 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R5212 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5213 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5214 NRSA63J-181X MG RESISTOR 180
Ω
1/16W J
R5215 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R5216 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R5217 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5240 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5241 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R5242 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5243 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5251 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R5253 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5254 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5255 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5258 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5259 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5261 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R5262 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R5263 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R5265 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5269 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R5270 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R5384 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5385 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5386 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5387 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R5391 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5392 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5393 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R5394 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R5395 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5396 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5501 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5502 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5503 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5504 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5505 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5507 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5508 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5509 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5510 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5511 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5512 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5513 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R5514 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5515 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5516 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5517 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5519 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R5520 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R5521 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R5522 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5523 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5524 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5526 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5527 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R5532 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5533 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R5541 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5542 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5543 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R5544 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R5545 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R5546 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R5558 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5559 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5560 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5561 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5564 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R5565 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L5202 QQL244K-150Z COIL 15uH K
L5211 QQL244K-4R7Z COIL 4.7uH K
L5241 QQL244K-4R7Z COIL 4.7uH K
L5243 QQL244K-4R7Z COIL 4.7uH K
L5244 QQL244K-4R7Z COIL 4.7uH K
L5261 QQL244K-150Z COIL 15uH K
Ref No. Part No. Part Name Description Local
CN5001 QGB1505K1-35 CONNECTOR B-B (1-35)
CN5006 QGA2501C5-05Z CONNECTOR W-B (1-5)
J5501 QNZ0454-001 AV JACK S/V/L/R IN
J5502 QNN0349-001 PIN JACK V/L/R IN
J5503 QNN0348-001 PIN JACK L/R OUT
Ref No. Part No. Part Name Description Local
C6401 QETN1HM-106Z E CAPACITOR 10uF 50V M
C6402 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C6403 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
R6401 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R6402 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R6403 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R6702 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6703 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6704 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R6705 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R6706 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
CN6006 QJB003-054010 SIN ID C-B WIRE
CN6007 QJB003-064426 SIN ID C-B WIRE
CN600B QJB003-050806 SIN ID C-B WIRE
J6401 QNN0281-003 PIN JACK V IN
J6402 QNN0281-002 PIN JACK L IN
J6403 QNN0282-001 PIN JACK R IN
LC6401 QQR1199-001 EMI FILTER
S6702 QSW0619-003Z TACT SWITCH MENU
S6703 QSW0619-003Z TACT SWITCH CH-
S6704 QSW0619-003Z TACT SWITCH CH+
S6705 QSW0619-003Z TACT SWITCH VOL-
S6706 QSW0619-003Z TACT SWITCH VOL+
Ref No. Part No. Part Name Description Local
IC7701 GP1UM281QK IR DETECT UNIT 38kHz
Q7702 UN2112-X TRANSISTOR
D7701 LG22440 LED POWER
C7701 QETN1EM-476Z E CAPACITOR 47uF 25V M
R7708 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R7709 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R7710 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7711 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
CN700B QGA2501C5-05Z CONNECTOR W-B (1-5)
S7701 QSW0847-001 TACT SWITCH POWER
Ref No. Part No. Part Name Description Local
