SECTION 5
TROUBLE SHOOTING
5.1 SELF CHECK INDICATING FUNCTION
The self check function begins detection about 5 seconds after
power is supplied.
In the event a malfunction is detected, the sub-power is cut off
immediately.
At this time, the ON TIMER LED flashes to inform of the
malfunction.
[ON-TIMER LED indication]
Item LED ON / OFF intervals
B1 over current / NECK 0.5-second (ON / OFF)
POWER
Supplied
SUB-POWER OFF
After about
5 seconds
Detection
start
Malfunction
is detected
Flashing
ON-TIMER LED
