JVC AV-27FA44/BSA - PRINTED WIRING BOARD PARTS LIST [AV-32 FA44;AZA]; MAIN P.W. BOARD ASSY (SGJ-1510 A-M2)

3-12(No.52114)
PRINTED WIRING BOARD PARTS LIST [AV-27FA44 /AZA]
MAIN P.W. BOARD ASS'Y (SGJ-1509A-M2)
 Ref No. Part No. Part Name Description Local
IC101 M52342SP IC
IC201 TM8812CSDNG4RR3 IC(MCU)
IC421 LA7841 IC
IC502 CXA1875AM-X IC
IC621 AN5277 IC
IC702 AT24C04W-32FA44 IC (SERVICE)
IC703 S-80840CNY-T IC
IC704 AN78L05-T IC
IC851 AN7812F IC
IC852 AN7809F IC
IC853 AN7805F IC
 IC911 STR-F6626/F3 IC
 IC921 SE135N IC
Q001 UN2212-X DIGI TRANSISTOR
Q101 2SC5083/L-P/-T TRANSISTOR
Q131 2SB709A/QR/-X TRANSISTOR
Q161 2SD601A/QR/-X TRANSISTOR
Q211 2SD601A/QR/-X TRANSISTOR
Q232 2SD601A/QR/-X TRANSISTOR
Q233 2SD601A/QR/-X TRANSISTOR
Q352 2SD601A/QR/-X TRANSISTOR
Q353 2SD601A/QR/-X TRANSISTOR
Q431 UN2212-X DIGI TRANSISTOR
Q501 2SC4212/Z1/ TRANSISTOR
 Q511 2SD2645-YD TRANSISTOR H OUT
Q531 2SC2785/JH/-T SI TRANSISTOR
Q532 2SB709A/QR/-X TRANSISTOR
Q541 2SB709A/QR/-X TRANSISTOR
Q542 2SB709A/QR/-X TRANSISTOR
Q543 2SD1408/OY/-LB POW TRANSISTOR
Q622 2SD601A/QR/-X TRANSISTOR
Q623 UN2212-X DIGI TRANSISTOR
Q624 2SB709A/QR/-X TRANSISTOR
Q625 2SB709A/QR/-X TRANSISTOR
Q626 2SD601A/QR/-X TRANSISTOR
Q627 2SD601A/QR/-X TRANSISTOR
Q701 2SB709A/QR/-X TRANSISTOR
Q951 2SD1383K/AB/-X TRANSISTOR
Q971 2SA1208/ST/Z1-T TRANSISTOR
D305 1SS133-T2 DIODE
D306 1SS133-T2 DIODE
D307 1SS133-T2 DIODE
D308 1SS133-T2 DIODE
D309 1SS133-T2 DIODE
D310 1SS133-T2 DIODE
D352 MTZJ9.1C-T2 Z DIODE
D353 1SS133-T2 DIODE
D354 MTZJ3.3A-T2 Z DIODE
D421 1N4003-T2 SI DIODE
D422 MTZJ75-T2 Z DIODE
D432 1SS133-T2 DIODE
D501 RH3G-F1 SI DIODE
D502 RU3AM-LFC4 SI DIODE
D507 RGP10J-5025-T3 SI DIODE
D521 RH1S-T3 SI DIODE
D523 RGP10J-5025-T3 SI DIODE
D525 1SS81-T5 SI DIODE
D526 1SS81-T5 SI DIODE
D527 1SR124-400A-T2 SI DIODE
D529 MTZJ9.1C-T2 Z DIODE
 D531 MA4068N/Z1/-T2 Z DIODE
D535 1SS133-T2 DIODE
D537 1SR35-400A-T2 SI DIODE
D601 MTZJ9.1C-T2 Z DIODE
D602 MTZJ9.1C-T2 Z DIODE
D603 MTZJ9.1C-T2 Z DIODE
D621 1SS133-T2 DIODE
D622 1SS133-T2 DIODE
D630 1SS133-T2 DIODE
D631 1SS133-T2 DIODE
D632 1SS133-T2 DIODE
D700 MTZJ5.6B-T2 Z DIODE
D701 1SS133-T2 DIODE
D703 MTZJ5.6B-T2 Z DIODE
D704 MTZJ5.6B-T2 Z DIODE
D705 1SS133-T2 DIODE
D706 MTZJ5.6B-T2 Z DIODE
D707 MTZJ5.6B-T2 Z DIODE
D708 MTZJ5.6B-T2 Z DIODE
D709 MTZJ5.6B-T2 Z DIODE
D723 MTZJ5.6B-T2 Z DIODE
D810 MTZJ5.6B-T2 Z DIODE
 D901 GSIB460-S1 BRIDGE DIODE
D910 MA700A-T2 SB DIODE
D911 RGP10J-5025-T3 SI DIODE
D912 RGP10J-5025-T3 SI DIODE
D913 RGP10J-5025-T3 SI DIODE
D914 1SS133-T2 DIODE
D915 SARS01-T2 SI DIODE
D917 MTZJ30A-T2 Z DIODE
D918 MTZJ5.1C-T2 Z DIODE
D920 1SS133-T2 DIODE
D931 RU30A-F1 SI DIODE
D933 RU3YX-LFC4 SI DIODE
D935 RU3YX-LFC4 SI DIODE
D937 RU3YX-LFC4 SI DIODE
D941 MTZJ33A-T2 Z DIODE
D945 MTZJ9.1B-T2 Z DIODE
D952 1SS133-T2 DIODE
D953 1SS133-T2 DIODE
D954 1SR35-400A-T2 SI DIODE
D955 1SR35-400A-T2 SI DIODE
D956 1SR35-400A-T2 SI DIODE
D957 1SR35-400A-T2 SI DIODE
D972 MTZJ15C-T2 Z DIODE
D973 1SS133-T2 DIODE
 PC921 TLP421F/D4-GR/ PHOTO COUPLER
C001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C003 QETN1HM-106Z E CAPACITOR 10uF 50V M
C004 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C106 QETN1EM-476Z E CAPACITOR 47uF 25V M
C107 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C113 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C114 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C116 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C117 QETN1EM-476Z E CAPACITOR 47uF 25V M
C118 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C119 NDC31HJ-681X C CAPACITOR 680pF 50V J
C120 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C124 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C131 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C161 QETN1HM-106Z E CAPACITOR 10uF 50V M
C163 NDC31HJ-470X C CAPACITOR 47pF 50V J
C164 NDC31HJ-470X C CAPACITOR 47pF 50V J
C165 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C166 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C202 QETN1HM-105Z E CAPACITOR 1uF 50V M
C203 NCB31HK-152X C CAPACITOR 1500pF 50V K
C211 QENC1CM-106Z BP E CAPACITOR 10uF 16V M
C212 NDC31HJ-100X C CAPACITOR 10pF 50V J
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C223 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C233 NDC31HJ-680X C CAPACITOR 68pF 50V J
C237 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C241 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C242 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C243 QETN1CM-107Z E CAPACITOR 100uF 16V M
C244 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C281 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C282 QETN1CM-107Z E CAPACITOR 100uF 16V M
C283 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C284 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C285 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C286 QETN1HM-106Z E CAPACITOR 10uF 50V M
C287 QETN1CM-107Z E CAPACITOR 100uF 16V M
C288 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C302 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C352 QETN1CM-476Z E CAPACITOR 47uF 16V M
C354 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C391 QETN1CM-107Z E CAPACITOR 100uF 16V M
C392 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C422 QFN32AK-102Z M CAPACITOR 1000pF 100V K
C424 QETN1VM-107Z E CAPACITOR 100uF 35V M
C425 QETN1VM-477Z E CAPACITOR 470uF 35V M
C427 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C428 QETM1EM-228 E CAPACITOR 2200uF 25V M
 Ref No. Part No. Part Name Description Local
