JVC AV-27FA44/BSA - EXPLODED VIEW PARTS LIST -2; EXPLODED VIEW -2

3-4(No.52114)
EXPLODED VIEW PARTS LIST -2
 Ref.No. Part No. Part Name Description Local
 V01 A68QCP893X003 ITC Inc. DY, PC MAGNET, WEDGE AV-27FA44/ASA
 V01 A68QCU754X62N ITC Inc. DY, PC MAGNET, WEDGE AV-27FA44/AZA
 V01 A80AJZ90X03 ITC Inc. DY, PC MAGNET, WEDGE AV-32FA44/AYA
 V01 A80ERF042X17 ITC
Inc. DY, PC MAGNET, WEDGE AV-32FA44/AZA
 V01 A90AJZ90X02 ITC Inc. DY, PC MAGNET, WEDGE AV-36FA44/AYA
 L01 QQW0090-001 DEG COIL AV-27FA44/ASA,AV-27FA44/AZA
 L01 QQW0107-001 DEG COIL AV-32FA44/AYA
 L01 QQW0176-001 DEG COIL AV-32FA44/AZA
 L01 QQW0122-001 DEG COIL AV-36FA44/AYA
 T502 QQH0121-001 FB TRANSF AV-27FA44/ASA
 T502 QQH0152-001 FB TRANSF AV-27FA44/AZA
 T502 QQH0125-001 FB TRANSF AV-32FA44/AYA,AV-36FA44/AYA
 T502 QQH0140-001 FB TRANSF AV-32FA44/AZA
3 A48457-4-S SPRING
4 WJY0016-001A BRAIDED ASSY AV-27FA44/ASA,AV-27FA44/AZA
4 WJY0016-002A BRAIDED ASSY AV-32FA44/AYA,AV32FA44/AZA
4 WJY0016-003A BRAIDED ASSY AV-36FA44/AYA
5 WJY0013-003A E-BRAIDED ASSY AV-27FA44/ASA,AV-27FA44/AZA,AV-32FA44/AYA,AV32FA44/AZA
5 WJY0013-002A E-BRAIDED ASSY (x2) AV-36FA44/AYA
6 LC21260-001B-A CONTROL KNOB
 7 GQ30034-001B-A WARNING LABEL
 8 LC10883-001C-A CHASSIS BASE
 9 LC20899-004A-A TERMINAL BOARD
10 QYSBSB3010Z TAP SCREW 3.0mm x 10mm(x4)
 11 QMPD390-200-JS POWER CORD(US/CA) 2m BLACK
 12 LC20106-001D-A POWER CORD CLAM
 13 LC11555-001A-A REAR COVER AV-27FA44/ASA,AV-27FA44/AZA
 13 LC11533-001A-A REAR COVER AV-32FA44/AYA,AV32FA44/AZA
 13 LC11559-001A-A REAR COVER AV-36FA44/AYA
14 QYSBSFG4016Z TAP SCREW 4mm x 16mm(x11)
 15 GQ30032-001A-A RATING LABEL
16 QAS0131-001 SPEAKER SP01, SP02(x2)
17 LC21261-001A-A SP HOLDER (x2)
18 LC41029-001A-A TAPPING SCREW (x4)
19 LC40226-002A-A SPACER (x4)
