JVC AV-27FA44/BSA - SPECIFICATION

1-2 (No.52114)
SPECIFICATION
Design & specifications are subject to change without notice.
Items
Contents
AV-27FA44 AV-32FA44 AV-36FA44
Dimensions (W × H × D)
82.9 cm × 59.3 cm × 51.9cm
(32-3/4"
× 23-3/8" × 20-1/2")
93.9 cm
× 68.5 cm × 50.0cm
(37"
× 27" × 22-1/2")
102.3 cm
× 75.6 cm × 61.3cm
(40-3/8"
× 29-7/8" × 24-1/4")
Mass 43.0kg (94.6Ibs) 64.0kg (140.8Ibs) 85.0kg (187.0Ibs)
TV RF System CCIR(M)
Color System NTSC
Sound System BTSC (Multi Channel Sound)
TV Receiving Channels
and Frequency
VHF LOW 02ch~06ch : 54MHz~88MHz
VHF HIGH 07ch~13ch : 174MHz~216MHz
UHF 14ch~69ch : 470MHz~806MHz
CATV 54MHz~804MHz
Low Band : 02~06, A-8 by 02~06&01
High Band : 07~13 by 07~13
Mid Band : A~I by 14~22
Super Band : J~W by 23~36
Hyper Band : W+1~W+28 by 37~64
Ultra Band : W+29~W+84 by 65~125
Sub Mid Band : A8, A4~A1 by 01, 96~99
TV / CATV Total Channel 180 Channels
Intermediate Frequency Video IF Carrier 45.75 MHz
Sound IF Carrier 41.25 MHz (4.5MHz)
Color Sub Carrier 3.58 MHz
Power Input AC120V , 60Hz
Power Consumption 140W 160W ←
Picture Tube (Visible size) 68cm (27”)
Measured diagonally
(H : 54.4cm × W : 41.8cm)
80cm (32”)
Measured diagonally
(H : 65.6cm × W : 49.6cm)
90cm (36”)
Measured diagonally
(H : 74.0cm × W : 55.9cm)
High Voltage 30.0kV ±1.3kV 31.4kV ±1.3kV ←
Speaker 6.5cm × 13cm (2-1/2" × 5"), Oval type × 2
Audio Power Output 10W + 10W
Antenna Terminal (VHF / UHF) F-type connector, 75 Ω unbalanced
Input1 (Rear) Video 1V(p-p), negative sync, 75 Ω, RCA pin jack × 1
S-video Mini DIN 4-pin × 1
Y : 1V(p-p), negative sync, 75 Ω
C : 0.286V(p-p)(burst signal), 75 Ω
Audio 500mV(rms)(-4dBs), high impedance, RCA pin jack × 2
Input2 (Rear) Video 1V(p-p), negative sync, 75 Ω, RCA pin jack × 1
Component Video Y : 1V(p-p), negative sync, 75 Ω, RCA pin jack × 1
Pb/Pr : 0.7V(p-p), 75 Ω, RCA pin jack × 2
Audio 500mV(rms)(-4dBs), high impedance, RCA pin jack × 2
Input3 (Front) Video 1V(p-p), negative sync, 75 Ω, RCA pin jack × 1
Audio 500mV(rms)(-4dBs), high impedance, RCA pin jack × 2
Audio Output (Fix) 500mV(rms)(-4dBs), low Impedance, (400kHz when modulated 100%),
RCA pin jack × 2
AV COMPULINK lll 3.5mm mini jack × 1
Remote Control Unit RM-C1251G (AA/R6/UM-3 battery × 2)
