3-14(No.52114)
R360 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R421 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R423 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R424 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R426 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R427 QRT029J-1R5 MF RESISTOR 1.5
Ω
2W J
R429 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R430 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R431 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R432 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R433 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R434 QRL029J-181 OMF RESISTOR 180
Ω
2W J
R435 QRE121J-102Y C RESISTOR 1k
Ω
1/2W J
R441 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R447 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R449 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R501 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R502 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R503 QRE121J-103Y C RESISTOR 10k
Ω
1/2W J
R504 QRL039J-152 OMF RESISTOR 1.5k
Ω
3W J
R505 QRL039J-182 OMF RESISTOR 1.8k
Ω
3W J
R506 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R508 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R509 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R511 QRE121J-220Y C RESISTOR 22
Ω
1/2W J
R512 QRE121J-681Y C RESISTOR 680
Ω
1/2W J
R513 QRL039J-273 OMF RESISTOR 27k
Ω
3W J
R515 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R516 QRZ0221-2R0 OMF RESISTOR 2
Ω
7W K
R524 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R526 QRE121J-272Y C RESISTOR 2.7k
Ω
1/2W J
R527 QRE121J-124Y C RESISTOR 120k
Ω
1/2W J
R528 QRE121J-154Y C RESISTOR 150k
Ω
1/2W J
R529 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R531 QRJ146J-391X UNF C RESISTOR 390
Ω
1/4W J
R532 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R533 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R534 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R535 NRVA02D-242X CMF RESISTOR 2.4k
Ω
1/10W D
R537 NRVA02D-682X CMF RESISTOR 6.8k
Ω
1/10W D
R538 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R541 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R543 QRE121J-122Y C RESISTOR 1.2k
Ω
1/2W J
R544 QRE121J-392Y C RESISTOR 3.9k
Ω
1/2W J
R545 QRE121J-822Y C RESISTOR 8.2k
Ω
1/2W J
R546 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R547 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R548 QRE121J-152Y C RESISTOR 1.5k
Ω
1/2W J
R553 QRL039J-390 OMF RESISTOR 39
Ω
3W J
R554 QRK126J-150X UNF C RESISTOR 15
Ω
1/2W J
R555 QRX029J-3R3 MF RESISTOR 3.3
Ω
2W J
R561 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R562 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R601 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R602 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R603 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R610 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R611 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R612 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R621 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R622 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R623 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R624 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R626 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R627 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R628 QRK126J-102X UNF C RESISTOR 1k
Ω
1/2W J
R629 QRK126J-102X UNF C RESISTOR 1k
Ω
1/2W J
R631 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R632 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R633 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R637 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R638 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R639 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R640 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R641 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R644 QRJ146J-2R2X UNF C RESISTOR 2.2
Ω
1/4W J
R645 QRJ146J-2R2X UNF C RESISTOR 2.2
Ω
1/4W J
R647 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R648 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R649 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R650 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R651 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R653 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R656 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R657 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R700 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R701 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R702 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R704 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R705 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R706 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R707 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R708 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R709 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R715 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R718 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R728 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R729 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R731 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R732 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R733 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R734 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R740 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R764 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R765 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R766 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R767 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R769 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R772 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R811 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R812 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R816 NRSA63J-124X MG RESISTOR 120k
Ω
1/16W J
R821 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R822 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R827 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R857 QRL029J-820 OMF RESISTOR 82
Ω
2W J
R901 QRF074K-1R2 UNF WW RESISTOR 1.2
Ω
7W K
R909 QRG01GJ-470 OMF RESISTOR 47
Ω
1W J
R911 QRE121J-223Y C RESISTOR 22k
Ω
1/2W J
R912 QRT029J-R18 MF RESISTOR 0.18
Ω
2W J
R913 QRT029J-R15 MF RESISTOR 0.15
Ω
2W J
R914 QRK126J-681X UNF C RESISTOR 680
Ω
1/2W J
R915 QRK129J-6R8 UNF C RESISTOR 6.8
Ω
1/2W J
R917 QRK126J-332X UNF C RESISTOR 3.3k
Ω
1/2W J
R918 QRE121J-222Y C RESISTOR 2.2k
Ω
1/2W J
R919 QRE121J-684Y C RESISTOR 680k
Ω
1/2W J
R924 QRE121J-222Y C RESISTOR 2.2k
Ω
1/2W J
R930 QRE121J-223Y C RESISTOR 22k
Ω
1/2W J
R939 QRT039J-1R5 MF RESISTOR 1.5
Ω
3W J
R940 QRE121J-181Y C RESISTOR 180
Ω
1/2W J
R941 QRL029J-183 OMF RESISTOR 18k
Ω
2W J
R950 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R951 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R952 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R953 QRE121J-820Y C RESISTOR 82
Ω
1/2W J
R973 QRE121J-272Y C RESISTOR 2.7k
Ω
1/2W J
R975 QRE121J-223Y C RESISTOR 22k
Ω
1/2W J
R977 QRE121J-473Y C RESISTOR 47k
Ω
1/2W J
R978 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R979 QRT029J-1R0 MF RESISTOR 1
Ω
2W J
R980 QRT029J-1R0 MF RESISTOR 1
Ω
2W J
R998 QRZ9041-275 C RESISTOR 2.7M
Ω
1/2W K
R999 QRE121J-121Y C RESISTOR 120
Ω
1/2W J
L001 QQL244K-560Z COIL 56uH K
L101 QQLZ014-R22 COIL 0.22uH 100mA L
L113 QQL244K-4R7Z COIL 4.7uH K
L131 QQL244K-150Z COIL 15uH K
L161 QQL244K-220Z COIL 22uH K
L232 QQL244K-560Z COIL 56uH K
L241 QQL244K-220Z COIL 22uH K
L391 QQL244K-220Z COIL 22uH K
L511 QQR1165-004 LINEARITY COIL
L512 QQLZ036-821 COIL 820uH K
L521 QQLZ026-800 COIL 80uH
±
7%
L701 QQL244K-220Z COIL 22uH K
L702 QQL244K-220Z COIL 22uH K
L703 QQL244K-220Z COIL 22uH K
L704 QQL244K-220Z COIL 22uH K
L705 QQL244K-220Z COIL 22uH K
L931 QQL26AK-470Z COIL 47uH K
L933 QQL26AK-470Z COIL 47uH K
L937 QQL26AK-470Z COIL 47uH K
L940 QQR0582-001Z FERRITE BEADS
T111 QQR0907-001 IFT
T501 CE42034-002 HOR DRIVE TRANS
T921 QQS0225-001 SW TRANSF
T951 QQT0372-001 POWER TRANSF
CF001 QAX0349-001 C TRAP 47.25MHz
CF131 QAX0639-001Z C TRAP 4.500MHz
Ref No. Part No. Part Name Description Local
To Next Page
