Types of Possible Input Signals
Single - DP1 - DP2
Original Input Signal
Designation Resolution
Projector
Terminal for
Connection
Resolution fh [kHz] fv [Hz]
dot CLK
[MHz]
Total No.
of Dots
[dot]
Total No.
of Lines
[line]
No. of
Effective
Dots [dot]
No. of
Effective
Lines
[line]
VGA 640 x 480
[DP 1] /
[DP 2]
640 x 480 31.469 59.940 25.18 800 525 640 480
1080p 1920 x 1080 1920 x 1080 56.250 50.000 148.50 2640 1125 1920 1080
67.433 59.940 148.35 2200 1125 1920 1080
67.500 60.000 148.50 2200 1125 1920 1080
2K 2048 x 1080 2048 x 1080 56.250 50.000 148.50 2640 1125 2048 1080
67.433 59.940 148.35 2200 1125 2048 1080
67.500 60.000 148.50 2200 1125 2048 1080
UXGA 1600 x 1200 1600 x 1200 75.000 60.000 162.00 2160 1250 1600 1200
WUXGA 1920 x 1200 1920 x 1200 74.556 59.885 193.25 2592 1245 1920 1200
QXGA 2048 x 1536 2048 x 1536 95.446 59.954 267.25 2800 1592 2048 1536
WQXGA 2560 x 1600 2560 x 1600 99.458 59.987 348.50 3504 1658 2560 1600
4K 3840 x 2160 3840 x 2160 53.946 23.976 296.70 5500 2250 3840 2160
54.000 24.000 297.00 5500 2250 3840 2160
56.250 25.000 297.00 5280 2250 3840 2160
67.433 29.970 296.70 4400 2250 3840 2160
67.500 30.000 297.00 4400 2250 3840 2160
112.500 50.000 594.00 5280 2250 3840 2160
134.865 59.940 593.41 4400 2250 3840 2160
135.000 60.000 594.00 4400 2250 3840 2160
4096 x 2160 4096 x 2160 53.946 23.976 296.70 5500 2250 4096 2160
54.000 24.000 297.00 5500 2250 4096 2160
56.250 25.000 297.00 5280 2250 4096 2160
67.433 29.970 296.70 4400 2250 4096 2160
67.500 30.000 297.00 4400 2250 4096 2160
112.500 50.000 594.00 5280 2250 4096 2160
134.865 59.940 593.41 4400 2250 4096 2160
135.000 60.000 594.00 4400 2250 4096 2160
* For WQXGA, the display is dot-by-dot.
