1-2 (No.MB080)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section Output Power SUBWOOFERS 120 W per channel, min. RMS, driven into 6 Ω at 63 Hz with no more
than 10% total harmonic distortion.
MAIN SPEAKERS 60 W per channel, min. RMS, driven into 4 Ω at 1 kHz with no more
than 10% total harmonic distortion.
Audio input sensitivity/
Impedance
(at 1 kHz, measured at
MAIN SPEAKERS)
AUX 400 mV/50 kΩ
Speakers/Impedance Subwoofers 6 Ω - 16 Ω
Main speakers 4 Ω - 8 Ω
Tuner FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 530 kHz - 1 710 kHz
CD player CD Capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Cassette deck Frequency response
Normal (type I)
50 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 120 V , 60 Hz
Power consumption 160 W (at operation)
18 W (on standby)
Dimensions (approx.) 270 mm × 317 mm × 453 mm (W/H/D)
Mass (approx.) 8.8 kg
Speaker section Type 3-way bass-reflex type
Speaker units Subwoofer 13.5 cm cone ×1
Main Woofer 16 cm cone ×1
Tweeter 5 cm cone ×1
Power handling capacity Subwoofer 120 W
Main speaker 60 W
Impedance Subwoofer 6 Ω
Main speaker 4 Ω
Frequency range Subwoofer 30 Hz - 70 Hz
Main speaker 70 Hz - 20 000 Hz
Sound pressure level Subwoofer 73 dB/W
·m
Main speaker 86 dB/W
·m
Dimensions (approx.) 290 mm × 317 mm × 336 mm (W/H/D)
Mass (approx.) 5.5 kg each
