3-9
Cassette mechanism
Block No. [M][P][M][M]
Symbol No.
Part No. Part Name Description Local
1 AH81-00472A R/P HEAD TC881CB067P(x2)
2 AH81-00472B E HEAD TC2131
3 AH81-00472N PINCH ROLLER 22-027-41054(x2)
4 AH81-00902E MOTOR ASSY 50-093-4879
5 AH81-00902G BF BELT 02-083-4236
6 AH81-00902J AF BELT 02-083-4234
7 AH81-00902K FR BLET 02-083-4188(x2)
8 AH81-00902L SOLENOID ASSY 50-093-4748(x2)
10 AH81-00902Q HOUSING 6216016100
11 AH81-00472V CLUTCH ASSY 50-093-4503(x2)
12 AH81-00902W MODE SWITCH MPU11570MLB0
13 AH81-00902X PHOTO INTERRUPT RP1352
14 AH81-00902Y LEAF SWITCH LSA11355
15 AH81-00903A SPRING62 01-082-4686(x2)
16 AH81-00473H SPRING 04 01-080-4635(x2)
