JVC MX-GA8 Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 AH64-02252D FRONT CABINET
2 AH64-02253B CASSETTE DOOR A
3 AH64-02254B CASSETTE DOOR B
4
 AH64-02255B CD DOOR
5 AH64-02256F WINDOW VFD
6 AH64-02257A WINDOW DOOR A
7 AH64-02258A WINDOW DOOR B
8 AH640-2259B KNOB DISC
9 AH64-02260B KNOB POWER
11 AH64-02262B KNOB REC
12 AH64-02263B KNOB REPEAT
13 AH64-02264B KNOB SOUND (x2)
14 AH64-02265B KNOB VOLUME
15 AH64-02266B DECO RING
16 AH64-02267B KNOB TURBO
17 AH64-02268B KNOB TAPE
19 AH64-02270B KNOB FUNCTION L
20 AH64-02271B KNOB FUNCTION R
22 AH67-00200B LENS DISC
23 AH67-00201A LENS POWER
24-1 AH67-00202B LENS-EQ L1 ROCK
24-2 AH67-00202C LENS-EQ L2 POP
24-3 AH67-00202D LENS-EQ L3 CLASSIC
25-1 AH67-00203B LENS-EQ R1 DANCE
25-2 AH67-00203C LENS-EQ R2 HALL
25-3 AH67-00203D LENS-EQ R3 STADIUM
26 AH67-00204B LENS INNER L
27 AH67-00205B LENS INNER R
28 AH67-00208A LENS MILKY (x2)
29 AH61-01258A VFD HOLDER
30 AH63-00507A SHEET MIRROR
31 AH61-01261A PCB BRAKET
32 AH61-01262A H SINK BRAKET (x2)
33 AH64-02273D REAR CABINET
34 AH62-00042A HEAT SINK 4959
35 AH63-00278A PCB COVER
36 AH61-40014A SUPPORT RIVET
37 AH95-50001A LATCH ASSY (x2)
38 AH61-80030A DAMPER ASSY (x2)
39 AH61-00552A DOOR SPRING A
40 AH61-00553A DOOR SPRING B
41 AH64-00462C BADGE JVC
42 AH64-30416E BOTTOM CABINET
43 AH64-30390K TOP CABINET
44 AH69-20031A CUSHION FOOT (x2)
45 AH63-00250B HEAT SINK COVER
46 AH62-00080A HEAT SINK MAIN
 47 AH26-00228A TRANS POWER 120V 40.5/40/4
53 AH07-00098B VF DISPLAY HNAC17LM04T
 56 AH39-00258V POWER CORD EP2 NO 125V 7A
57 AH39-50001X GROUND WIRE
59 AH61-01400A HOLDER DECK
60 AH64-02551B CAP DECK
61 AH40-00044A TUNER PACK ASSY KST-MJ011MS0-60
62 AH68-01253N RATING LABEL
63 AH68-50275D STICKER CD
64 AH68-50282K CAUTION LABEL
65 AH68-00486A CAUTION LABEL B
66 AH64-01106G SCREW M3X10 SILVER(x4)
67 6002-000126 SCREW FH M3X10 BLK(x3)
68 6003-000276 SCREW
BH M3X10
YEL(x40)
69 6003-000275 SCREW
BH M3X10
BLACK(x27)
70 AH60-10107A SCREW M4X6 YEL(x4)
71 6003-000277 SCREW BH M3X12 YEL(x4)
72 6002-000398 SCREW BH M3X6 YEL(x3)
73 6003-001230 SCREW BH M3X14 YEL(x4)
74 6003-000283 SCREW BH M3X8 YEL(x3)
