JVC MX-GA8 Service Manual

3-14
Amp. board
Block No. [0][3][0][0]
UR135 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR136 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR137 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR138 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR139 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR140 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR141 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR142 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR143 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR144 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR145 2001-000522 CARBON RESISTOR 22K 5% 1/8W
UR146 2001-000522 CARBON RESISTOR 22K 5% 1/8W
UR147 2001-000522 CARBON RESISTOR 22K 5% 1/8W
UR148 2001-000449 CARBON RESISTOR 2.2K 5% 1/8W
UR149 2001-000734 CARBON RESISTOR 4.7K 5% 1/8W
UR150 2001-000522 CARBON RESISTOR 22K 5% 1/8W
UR152 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR153 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR154 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR155 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR156 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR157 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR158 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR159 2001-000034 CARBON RESISTOR 220 5% 1/4W
UR160 2001-001178 CARBON RESISTOR 680 5% 1/2W
UR161 2001-001178 CARBON RESISTOR 680 5% 1/2W
UR162 2001-001178 CARBON RESISTOR 680 5% 1/2W
UR166 2001-000613 CARBON RESISTOR 3.9K 5% 1/8W
UR170 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR171 2001-000290 CARBON RESISTOR 10K 5% 1/8W
UR172 2001-000786 CARBON RESISTOR 47K 5% 1/8W
UR173 2001-000786 CARBON RESISTOR 47K 5% 1/8W
UR180 2001-000008 CARBON RESISTOR 15K 5% 1/8W
UR181 2001-000660 CARBON RESISTOR 33K 5% 1/8W
UR182 2001-000281 CARBON RESISTOR 100 5% 1/8W
UR183 2001-000786 CARBON RESISTOR 47K 5% 1/8W
UR184 2001-000786 CARBON RESISTOR 47K 5% 1/8W
UX101 2801-001394 CRYSTAL 32.768KHZ 20PPM
UX102 2802-001174 RESONATOR 10MHZ 0.5%
XXX AH94-01145A TAPG ASSY FRONT-AUTO
ZD101 0403-000334 Z DIODE UZ2.7BSA 2.7V
ZD102 0403-000334 Z DIODE UZ2.7BSA 2.7V
ZD103 0403-000334 Z DIODE UZ2.7BSA 2.7V
ZD104 0403-000361 Z DIODE UZ6.2BSB 6.2V
 Symbol No. Part No. Part Name Description Local
 PW101 3711-000190 CONNECTOR 2P 1R 7.92MM
PC101 2201-002128 C CAPACITOR 4.7NF 20% 400V
PC102 2201-002128 C CAPACITOR 4.7NF 20% 400V
R52 2001-000110 CARBON RESISTOR 10 5% 1/4W
AC36 2401-000438 E CAPACITOR 10UF 20% 25V
AC37 2401-001511 E CAPACITOR 47UF 20% 16V
AC41 2301-000375 M CAPACITOR 100NF 10% 50V
AC52 2401-001538 E CAPACITOR 47UF 20% 25V
AC10L 2202-000263 C CAPACITOR 470PF 10% 50V
AC10R 2202-000263 C CAPACITOR 470PF 10% 50V
AC11L 2201-000557 C CAPACITOR 0.47NF 10% 50V
AC11R 2201-000557 C CAPACITOR 0.47NF 10% 50V
AC12L 2201-000838 C CAPACITOR 0.003NF 0.25PF
AC12R 2201-000838 C CAPACITOR 0.003NF 0.25PF
AC13L 2301-000375 M CAPACITOR 100NF 10% 50V
AC13R 2301-000375 M CAPACITOR 100NF 10% 50V
AC20L 2202-000263 C CAPACITOR 470PF 10% 50V
AC20R 2202-000263 C CAPACITOR 470PF 10% 50V
AC21L 2201-000146 C CAPACITOR 0.1NF 5% 50V
AC21R 2201-000146 C CAPACITOR 0.1NF 5% 50V
AC22L 2201-000838 C CAPACITOR 0.003NF 0.25PF
 Symbol No. Part No. Part Name Description Local
AC22R 2201-000838 C CAPACITOR 0.003NF 0.25PF
AC25L 2301-000375 M CAPACITOR 100NF 10% 50V
AC25R 2301-000375 M CAPACITOR 100NF 10% 50V
AC30L 2301-000412 M CAPACITOR 22NF 10% 50V
AC30R 2301-000412 M CAPACITOR 22NF 10% 50V
AC33L 2301-000412 M CAPACITOR 22NF 10% 50V
AC33R 2301-000412 M CAPACITOR 22NF 10% 50V
AC50L 2201-000381 C CAPACITOR 22NF +80% 50V
AC50R 2201-000381 C CAPACITOR 22NF +80% 50V
AC51L 2201-000381 C CAPACITOR 22NF +80% 50V
AC51R 2201-000381 C CAPACITOR 22NF +80% 50V
AC603 2201-000783 C CAPACITOR 100NF +80-20% 5
AC604 2201-000783 C CAPACITOR 100NF +80-20% 5
AC607 2201-000532 C CAPACITOR 4.7NF 10% 50V
AC608 2201-000532 C CAPACITOR 4.7NF 10% 50V
ACW1 3708-001167 CONNECTOR 14P 1.25MM
ACW2 3711-003113 CONNECTOR 9P 1R 2.5MM
AD100 1N4148 GE DIODE 0401-000101
AD101 1N4148 GE DIODE 0401-000101
AD102 1N4148 GE DIODE 0401-000101
AD103 1N4148 GE DIODE 0401-000101
AD104 1N4148 GE DIODE 0401-000101
AD105 1N4148 GE DIODE 0401-000101
AD303 1N4002 FR DIODE 0402-000127
AD304 1N4002 FR DIODE 0402-000127
AE100 2401-000357 E CAPACITOR 100UF 0.2 50V
AE101 2401-001164 E CAPACITOR 33UF 20% 16V
AE102 2401-000357 E CAPACITOR 100UF 0.2 50V
AE103 2401-000357 E CAPACITOR 100UF 0.2 50V
AE10L 2401-002180 E CAPACITOR 2.2UF 20% 50V
AE10R 2401-002180 E CAPACITOR 2.2UF 20% 50V
AE11L 2401-000407 E CAPACITOR 10UF 20% 16V
AE11R 2401-000407 E CAPACITOR 10UF 20% 16V
AE200 2401-000230 E CAPACITOR 100UF 20% 100V
AE201 2401-000230 E CAPACITOR 100UF 20% 100V
AE202 2401-000230 E CAPACITOR 100UF 20% 100V
AE203 2401-000357 E CAPACITOR 100UF 0.2 50V
AE204 2401-000357 E CAPACITOR 100UF 0.2 50V
AE205 2401-000230 E CAPACITOR 100UF 20% 100V
AE206 2401-001538 E CAPACITOR 47UF 20% 25V
AE20L 2401-002180 E CAPACITOR 2.2UF 20% 50V
AE20R 2401-002180 E CAPACITOR 2.2UF 20% 50V
AE21L 2401-000407 E CAPACITOR 10UF 20% 16V
AE21R 2401-000407 E CAPACITOR 10UF 20% 16V
AE500 2401-001895 E CAPACITOR 100UF 20% 16V
AE501 2401-001895 E CAPACITOR 100UF 20% 16V
AE50L 2401-000459 E CAPACITOR 10UF 20% 35V
AE50R 2401-000459 E CAPACITOR 10UF 20% 35V
AJW9 2001-000331 CARBON RESISTOR 12K 5% 1/8W
AL10R AH27-90001A COIL SPRING 2.2UH
AL1OL AH27-90001A COIL SPRING 2.2UH
AL20L AH27-90001A COIL SPRING 2.2UH
AL20R AH27-90001A COIL SPRING 2.2UH
AQ03 KTA1268 TRANSISTOR 0501-000630
AQ04 KTC3200 TRANSISTOR 0501-000440
AQ05 KTC3199-Y TRANSISTOR 0501-000014
AQ06 KTC3199-Y TRANSISTOR 0501-000014
AQ01L KTA1268 TRANSISTOR 0501-000630
AQ01R KTA1268 TRANSISTOR 0501-000630
AQ02L KTA1268 TRANSISTOR 0501-000630
AQ02R KTA1268 TRANSISTOR 0501-000630
AQ100 KTC8050 TRANSISTOR 0501-002375
AQ10L KTC8050 TRANSISTOR 0501-002375
AQ10R KTC8050 TRANSISTOR 0501-002375
AQ201 KTD863 TRANSISTOR 0501-002176
AQ202 KTA1273 TRANSISTOR 0501-000422
AQ301 KTD863 TRANSISTOR 0501-002176
AQ401 KTD863 TRANSISTOR 0501-002176
AQ50L KTC8050 TRANSISTOR 0501-002375
AQ50R KTC8050 TRANSISTOR 0501-002375
AQ603 KTC8050 TRANSISTOR 0501-002375
AR15 2009-001081 OMF RESISTOR 0.22 5% 7W
AR24 2009-001081 OMF RESISTOR 0.22 5% 7W
AR25 2009-001081 OMF RESISTOR 0.22 5% 7W
AR31 2009-001081 OMF RESISTOR 0.22 5% 7W
AR44 2001-000290 CARBON RESISTOR 10K 5% 1/8W
AR45 2001-000273 CARBON RESISTOR 100K 5% 1/8W
AR46 2001-000273 CARBON RESISTOR 100K 5% 1/8W
 Symbol No. Part No. Part Name Description Local
