JVC SR-W320U User Manual

3__RECORDING
Basic Operations
SP/EP
(HD/SD)
Preparations
1 Turn the power on.
2 Select the recording mode.
Which mode is available depends on the type of
the cassette in use.
Cassette in use
Recording mode
HD mode
SD mode
S-VHS mode
VHS mode
VHS mode
HD mode
a. Press the HD INPUT button.
b. Load the W-VHS tape. Then, HD lamp lights
and SP is shown on the front window display.
SD mode
a. Select L1, L2 or L3 with INPUT SELECT button.
b. Load the W-VHS tape. Then, SD lamp lights
and EP is shown on the front window display.
18
HI-FIAUD OUT AUDIO OUT
SELECT SELECT
Co GS
DISPLAY
S-VHS mode
a. Select Lt, L2 or L3 with INPUT SELECT button.
b. Load the S-VHS tape.
c. Select recording speed with the SP/EP (HD/SD)
button. Every pressing this button changes the
SP - EP — SP.
d. Set the [S-VHS REC] switch to AUTO. The [S-
VHS] jamp lights.
VHS mode
a. When using a S-VHS tape, set the S-VHS REC
switch to OFF.
The [S-VHS] jamp goes off.
With a VHS tape loaded, the VHS mode is
automatically entered.
b. Select recording speed with SP/EP button.
Set an optimum recording level with the AUTO
CAL button as required. (See page 20).
This facility does not work for the W-VHS tape.
5 RECORDING
ES a TE DE IT
Basic Operations
4 Adjust the HiFi recording level. 5 Start recording.
a. Call up the audio level meter display with the a. Press the REC button, whereupon recording
DISPLAY SELECT button. starts.
b. Select HiFi audio with the AUDIO OUT SELECT b. Press the PAUSE/STILL button for a brief pause
button. This shows the HiFi audio level meter of recording.
display. (See page 14). c. Pressing the PLAY button resumes recording.
c. Adjust the recording level and L/R balance. d. Press the STOP button to bring recording to an
While checking with the audio level meter, end.
adjust with the REC LEVEL and BALANCE
knobs, until the thick bars on the display
occasionally swing.
Perform adjustment carefully, as too low a
recording level may lead to a greater noise and
too high a level may cause a distortion.
Retake Function
You can cut the unnecessary part of the program
during recording. This facility does not work when
using a W-VHS tape.
End of Unnecessry part] Unnecessry part Program to
program |tobe recorded | to be recorded | be continued
a. With the pause mode entered, keep pressing the Recorded section
REW or FF button. The tape is played back at a
normal PLAY speed.
b. Leave your hand off the button at the start of the Resume recording with the PLAY button.
unnecessary part (where you want to adjoin the
program). Pause mode resumes where your hand End of Program to be continued.
has left the button. slay
c. Press the PLAY button at the part of the program
you want to continue recording. Recording
resumes.
with the FF or REW button.
Blank Search Function
Used to search the unrecorded section of the tape.
a. With the stop mode entered, press the BLANK
SEARCH button. Search stops where the
unrecorded section is found.
b. Press the STOP button if you want to cancel biank
search.
Pesan, mecca nd reenact ecnnasannes, nen ect ehe, eugene, oe
