805.57
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 07: Feeder Setup Data, Continued
Page 07
variable list
con't
Variable Name Edit? Description
Ext. Totalizer Increment ` This value determines how many
Lbs or Kgs are delivered for each
pulse that would be sent from the
controller to an external totalizer.
Range of Values
0 to 1,000,000,000
Default Value: 0
Feeder Type Selection ` This selection sets the loss-in-
weight software to work with the
correct feeder type. The "Q" prefix
is used only with the Quad
controller electronics.
VIB
LWF120<
LWF240
W300
W600
W1000
QLWF120
QLWF240
QWBF300
QWBF600
QWBF1000
QWBF-HF
PID
NOT USED
Caution: Only select the Vibratory
type if a vibratory feeder is used by
this controller since any change is
setpoints will result in the Feed
Factor Array being cleared. The
default value is " Screw Fdr" where
the array is not cleared upon
setpoint changes.(Rev. Z- LWF)
Continued on next page
