805.64
K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 07: Service Variable Index, Continued
Service
variable index
and value
listing con't
Bit Output 4 Same as Bit Output 1
FF0 thru FF10 Feedfactors at array
positions 0 thru 10
Read Only
SAB Analog Input
Assignment
This entry allows you
to set the function for
the SAB analog input
0 = Unassigned
1 = Setpoint
2 = Spd Feedback
3 = Calibrate
SAB Input Range This entry allows you
to set the range of the
incoming analog
signal to the SAB Bd.
0 = 0 to 1 V
1 = 0 to 5 V
2 = 1 to 5 V
3 = 0 to 10 V
4 = 0 to 20ma
5 = 4 to 20ma
SAB Current Input
Value
This is the freq value
of the current input.
0 - 10,000Hz Read
only
SAB Input Calib
Value
Refer to DCS# 564 for
Calib instructions
SAB Output
Assignment 1
This entry allows you
to select what the
output will represent.
0 = Unassigned
1 = Calib Output
2 = Massflow
3 = Setpoint
4 = Net Wt
5 = Drv Cmd
6 = Motor Spd
7 = Feedfactor
8 = Dev from SP
9 = Beltload
10 = Batch %
11 = Batch size
12 = Pre Fdr DC
SAB Output
Assignment 2
Same as Assignment
1
SAB Output
Assignment 3
Same as Assignment
2
Continued on next page
