K-Commander Loss-in-Weight Programming
Rev: G Produced by the K-Tron Institute
LWF Page 07: Service Variable Index, Continued
Service
variable index
and value
listing con't
FTS FDR 1
This entry selects
feeder 1 type
6 = QVIB
7 = QLWF120
8 = QLWF240
9 = QW300
10 = QW600
11 = QW1000
12 = QW-HF
13 = QPID
14 = Not used
FTS FDR 2 Same as above
FTS FDR 3 Same as above
Fr6 Hyster This entry sets the
hysteresis for freq
input #6
0 to 1000Hz
Fr6 Offset
This entry sets the
offset for freq input
#6
0 to 1000Hz
Spurious Case For software analysis
only
Nameplate Motor
Speed
Entered value of
Namplate motor
speed for
programmable motor
drive
Standard range is
1800 to 2500 rpm
Nameplate Motor
Power
Entered value of
Namplate motor
speed for software
programmable motor
drive
Units are watts.
Actual Motor Power Actual motor power
being drawn.
Continued on next page
