Kaba 5 00 Series User Manual

3
Model E5031
The E-Plex 5031 is a non-handed lock that is preassembled for
left-hand installations. It is field reversible.
TOOLS REQUIRED
• Safety glasses
• Electric drill (variable speed)
• Awl or center punch
• 2
1
⁄8” (54 mm) hole saw pilot drill
• 1” (25 mm) hole saw pilot drill
•
1
⁄4” (7 mm) drill bit
• 1” (25 mm) wood chisel
• Hammer
• Phillips head screwdriver
• Small flat blade screwdriver
For technical assistance please call
1-800-849-TECH (8324) or 336-725-1331
