10
B. MORTISE
Checklist and Exploded Views (Mortise Only)
Each E2x00 Mortise lockset includes:
(A) Outside lever handle
(or)
Parts for Mechanical override model only:
(A
1) Outside lever handle
(B
1) Outside housing
(C
1) Cylinder plug
(D
1) Cylinder (for locks with KIL option)
(E
1) Cylinder cap
(E
2) Instruction sheet “How to attach lever on lock”
(B) Outside housing
(C) Battery holder with 3 AA batteries (not for PowerStar versions)
(D) Mortise (ASM only shipped assembled with faceplate and 2 x 8-32 x
1
/
4
”
screws)
(E) Inside trim assembly, details depend on lock model
(E
3) Drilling template
(N) Outdoor Gasket (not for PowerStar versions)
Parts inside hardware bag:
(F) Thumbturn (hex) spindle
(G) Square spindle
(H) Phillips screw (6-32X 5/16”) (not for PowerStar versions)
(I) 3 x mounting screws (12-24, 1/8” Hex Head)
(J) 2 Machined screws (12-24X 1/2” Philips) & 2 wood screws (#12 X 1” Philips)
(K) Strike kit (screws, strike and dustbox)
(L) 1 extension spring
(R2) 1 Cylinder with 2 keys for E2x00 with override
(S) 3 spacers for recent Models only
(T) Allen Key 1/8”
(U) Allen Key 5/64”
