21
K. TESTING THE OPERATION OF THE LOCK
K-1 Rotate inside lever and hold. Ensure that the mortise latch is fully retract-
ed and flush with the mortise faceplate. Release the inside lever; the latch
should be fully extended.
K-2 Enter the factory-set combination: 1,2,3,4,5,6,7,8. You should see a green
light and hear a high-pitched tone as you push each button. When the lock
opens you will briefly hear the sound of an electric motor. If 1,2,3,4,5,6,7,8
does not seem to work, please follow the steps to perform a hard reset by
following the procedure in section L.
K-3 Rotate outside lever and hold. Ensure that the latch is fully retracted and
flush with the latch faceplate. Release the outside lever; the latch should
be fully extended. When the lock re-locks, you will again hear the motor.
K-4 Insert key into the outside lever. Rotate key counterclockwise to stop posi-
tion and hold. Ensure that the latch is fully retracted and flush with the
latch faceplate. Rotate the key clockwise to the horizontal position and
remove the key. The latch should be fully extended.
K-5 To test the deadbolt function (where applicable), turn the thumbturn knob
to extend the deadbolt. A red light should flash once. Then, turn the
thumbturn again and verify that the deadbolt is retracted and there is a
flash of the green light.
Note: Refer to the Operating Manual to set up lock operation.
L. PROGRAMMING AND SOFTWARE SETTINGS:
L-1 You must change the master Code from the factory default to another
code to program the lock. For further information on how to manually
program the E-Plex 3x00/5x00 Series Models, refer to the companion “E-
Plex 3x00/5x00 Operation Manual.” Software is required to program the
E3200/E5200 Series Locks.
L-2 When configuring the E3000/E5000 Series Locks using the optional
Standard Software, choose the box that contains “Entry Lock with
Passage (Cylindrical or Mortise without Deadbolt)” during lock setup.
L-3 When configuring the E3200/3700 and E5200/E5700 Series Locks
using the Enerprise Software, select the appropriate lock type during
lock setup.
