Introduction
The purpose of this manual is to instruct the installer on the proper installation
procedure for the E-Plex 5x66 and 5x67 1
1
⁄4" American Steel Mortise (ASM)
Mortise locks. These instructions pertain to models with and without deadbolts.
For models without deadbolts, please disregard any references to a thumbturn
in the instructions.
TOOLS REQUIRED
• Safety glasses
•
1
⁄2" (13 mm) chisel
•
1
⁄8" (3 mm) drill bit
•
1
⁄4" (7 mm) drill bit
•
1
⁄2" (13 mm) drill bit
• 2
1
⁄8" (54 mm) hole saw
• Drill
• Awl or center punch
• Hammer
• Small flat screwdriver
• Phillips screwdriver (#2)
• Fine steel file
• Mortising machine
• Router
• Mortise faceplate router
template
• Adjustable square
• Tape measure
• Pencil
• Tape
• Cleaning supplies
(drop cloth, vacuum)
OPERATIONAL NOTE:
The E-Plex Mortise lock is almost identical to the E-Plex 5000
Cylindrical lock with the following exceptions:
1. Operation of the Lever When the lock’s handing is properly
set, only a downward rotation of lever will actuate latch.
2. Key Override Use The key override differs in that rotating
the key does not actuate the latch. To use the key override
the key must be inserted into the cylinder and rotated count-
er clockwise until it stops (approximately 90 degrees) then
while holding the key in this position with one hand use the
other hand to rotate the lever downward to retract the latch.
Once the lever has rotated a few degrees the key may be
released.
