Kaba SIMPLEX 5000 CYLINDRICAL User Manual

21
P. TROUBLE SHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY
1. The outside lever/knob
always retracts the latch
after depressing and
releasing the “ENTER”
button only (without -
combination).
2. The outside lever/knob
always retracts the latch
after depressing and
releasing the “ENTER”
button only (without -
combination).
3. The outside lever/knob
will not go completely
inside the outside lock
assembly.
4. Correct combination is
depressed, but the latch
does not retract.
Lock is in “ZERO”
combination.
Activation cam has
flipped over during
lost combination
procedure
Lever catch is
misaligned.
Failed to depress the
“ENTER” button.
Follow the procedure for
Changing Combinations
(Section M) except omit steps
1 and 2 (do not enter the
existing combination).
Remove outside housing
from base, remove chamber
and flip activation cam back
to correct positon.
Insert release tool through
small hole on the outside
unit assembly (under the
lever/knob). Using the tool,
gently push
lever catch up
until it clicks. Refer to
Section I or J (Installing and
Removing the Outside
Lever/Knob).
Always depress and release
the “ENTER” button after
depressing the correct
combination.
