Kaba SIMPLEX 5000 CYLINDRICAL User Manual

TOOLS REQUIRED
• Safety glasses
• Electric drill (variable speed)
• Awl or center punch
• 2
1
⁄8" (54 mm) hole saw pilot drill
• 1" (25 mm) hole saw pilot drill
•
1
⁄4" (7 mm) drill bit
• 1" (25 mm) wood chisel
• Hammer
• Phillips head screw driver
• Small flat blade screwdriver
Inside Lever
Mounting Screws
I
nside Unit
Assembly
Outside Unit
Assembly
Outside Lever
Assembly
3
/4" (18mm) Screws
Latch
1" (25mm) Screws
Allen Wrench
Set Screw
ASA Strike
Release/Combination
Change Tool
Model 502x (shown)
The Simplex 5000 is a non-handed lock that is preassembled for
left-hand installations. It is field reversible.
For technical assistance please call
1.800.849.TECH (8324) or 336.725.1331
Warnings and Cautions
Important: Carefully inspect windows, door frame, door, lights, etc., to
ensure that the recommended procedures will not cause damage.
Kaba Access Control’s warranty does not cover damages caused by
installation.
Caution: Wear safety glasses when preparing door.
3
