9.9.4 Manually adjusting the Modbus address
 The required device is selected in
<Available inverters> and the <Inverter
values & settings> menu is opened.
Note: By default, the Modbus address
“3” is stored here and should not be
changed for an inverter. This value is
used for communication with the data
logger and Smart-Meter.
1. If necessary, enter a new value for
each additional inverter that follows the
first communication unit and <Confirm>
after entering.
» Modbus address configured.
Fig. 84. Select Modbus address
Fig. 85. View Modbus address
9.9.5 Enabling external write access
 You have the option of granting write
access for external protocols. Access
relates exclusively to the “Monitoring &
control” menu. See Chapter 9.7.2
Note: By default, the function is
disabled. After activation, take note of
the information field in the window
that appears.
1. If required, grant write access by
pressing <Confirm>.
» External write access granted via
SunSpec / KACO legacy protocol.
Fig. 86. Grant access to device via Sunspec
Modbus / Kaco legacy protocol
Fig. 87. Select external write access
Fig. 88. Confirm activation of
external write access

Kaco blueplanet 10.0 NX3 M2 Specifications

General

Model	blueplanet 10.0 NX3 M2
Manufacturer	Kaco
Category	Inverter
Max. AC Output Power	10000 W
Max. DC Voltage	1100 V
Number of MPPTs	2
Max. apparent AC power	10000 VA
AC frequency	50 Hz / 60 Hz
Max. AC current	16 A
Max. DC current	26 A
Protection class	IP65
Topology	Transformerless
Operating Temperature Range	-25°C to +60°C
Cooling	Convection
Max. DC power	15000 W
AC Output Voltage	230 V / 400 V
AC voltage range	230 V / 400 V
