4.2 General data
KACO blueplanet 3.0 NX3 M2 5.0 NX3 M2 8.0 NX3 M2 10.0 NX3 M2 15.0 NX3 M2 20.0 NX3 M2
Max. efficiency
97.28%
97.47%
97.69%
97.68%
97.75%
97.78%
Europ. Efficiency
95.82%
96.45%
97.03%
97.14%
97.33%
97.44%
Self consumption: Standby
5 W
Feed-in from
60 W
Transformer unit
no
Protection class / over voltage
category
I / III (AC) II (DC)
Grid monitoring
Country-specific
Distribution system
TN-C-System, TN-C-S-System, TN-S-System, TT-System
Display
LED
Controls
no
Menu languages
DE, EN
Interfaces
Communication unit /
RS485
Communication
WLAN, SunSpec Modbus TCP-IP /
SunSpec Modbus RTU, KACO Legacy Protocol
Radio technology
WLAN 802.11 b / g / n
Frequency spectrum
2,412 MHz - 2,472 MHz
Antenna gain
2 dBi
Potential-free relay
no
DC isolator switch
yes
AC isolator switch
no
Cooling
passive
Air cooling
Number of fans
0
1
Noise emission
< 40 dB(A)
< 45 dB(A)
Housing material
Aluminium
HxWxD
503 mm x 435 mm x 183 mm
Weight
16 kg
17 kg
18kg
Certifications
Overview: see website / download area
4.3 Environmental data
KACO blueplanet 3.0 NX3 M2 5.0 NX3 M2 8.0 NX3 M2 10.0 NX3 M2 15.0 NX3 M2 20.0 NX3 M2
Max. installation height
3,000m
Max. installation distance
from coast
3,000m
Ambient temperature
-25 °C …+60 °C
Power derating from
40 °C
Protection rating (KACO installation
location)
IP65
Humidity range (non-condensing)
[%]
100%
4.4 Accessories
Accessory articles KACO order no.
Eastron SDM630
3015600
