9
current, which may exceed the indicated value�
High-Impedance voltage measurement
High Impedance means high electrical Impedance� This is used to denote the input
Impedance or output Impedance of electrical circuits and devices in particular� When
measuring in the circuit, this has only a minor impact on the performance of the circuit,
particularly in the case of sensitive electronic circuits or control circuits�
Low-Impedance voltage measurement ( )
mode allows you to measure AC/DC voltages with a low impedance in this mode,
the Meter lowers the internal resistance to prevent ‘phantom’ voltage readings. As a
result, the circuit is more heavily loaded than in the standard measuring mode�
Attention
▶
When using
(low input impedance) measurement, the continuous measurement
time cannot exceed 1 minute�
▶
Do not use LoZ mode to measure the voltage in the circuit that may be damaged
due to the low impedance of this mode�
