Resistance measurement Ω
1. Turn the rotary function switch to for resistance measurement. It displays “MΩ”
on screen�
2. Turn o the circuit under test.
3� Plug the black test lead into the COM socket and the red test lead into the INPUT
socket�
4� Then place the test probes in contact with the points at which the resistance must be
measured�
5� Read the result on the display�
Note: When measuring resistance on a circuit, the
measured value can be inuenced by other circuits.
Overload protection: 250V
