12
Connecting test leads
Do not test if leads are improperly seated�
Results could cause intermittent display
readings� To ensure proper connection,
rmly press leads into the jack completely.
AC/ DC current measurement
• When making current measurements, disconnect the test leads from the Meter�
• Keep ngers behind Tactile Barrier(4).
• When measuring current, center the conductor in the Jaw using the alignment marks
on the Jaw�
• Before taking dc measurements, please push key to ensure correct readings�
Zeroing the Meter removes dc oset from the reading. The Zero function works only in
the dc current measurement�
• Before zeroing the Meter, make sure the Jaws are closed and there is no conductor
INCORRECT
CORRECT
Making Measurements
