15
voltage measurement�
2� Plug the black test lead into the COM socket and the red test lead into the INPUT
socket�
3� Then bring the test probes into contact with the points to be measured�
4� Read the measurement results on the display�
Attention
▶
When using
(low input impedance) measurement, the continuous measurement
time cannot exceed 1 minute�
▶
Do not use LoZ mode to measure the voltage in the circuit that may be damaged due
to the low impedance of this mode�
High impedance voltage measurement: 10 MΩ
Low impedance voltage measurement: 300 kΩ
