ZEUS-VD INSTALLER’S MANUAL
9.6 DIRECT ALARM OUTPUT – OD
If you want to activate a local alarm (siren) you can program any ZEUS4-VD output for this
function. OD5 to OD8 are links between fictive inputs like telephone line failure, GSM failure to
dedicated output.
Type of the Output (ON/OFF or pulse time) is determinate with parameter OS.
In the same time you can control the outputs also remotely by SMS or DTMF commands.
Possible programming parameters:
ZEUS4-VD - GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Output Description
OD1
N
o direct connection between input and outpu
t
OD2
N
o direct connection between input and outpu
t
OD3
N
o direct connection between input and outpu
t
OD4
N
o direct connection between input and outpu
t
OD5
Telephone line failure (ONLY MC version)
OD6
GSM network failure
OD7
System tamper
OD8
System ON/OFF (any of outputs)
9.6.1 Programming table for OD – direct alarm output
Example:
It is possible to choose different combinations between outputs and inputs
ZEUS4-VD - GSM PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name Output Description
OD1 1
Alarm on IN1 trigger output 1
OD2 0
N
o direct connection between input and outpu
t
OD3 0
N
o direct connection between input and outpu
t
OD4 0
N
o direct connection between input and output
OD5 X
Telephone line failure (ONLY MC version)
OD6 2
GSM network failure on output 2
OD7 4
System tamper on output 4
OD8 3
System ON/OFF on output 3
