ZEUS-VD INSTALLER’S MANUAL
5 START UP
⇒ Insert SIM card to be used for ZEUS4-VD in your personal mobile phone.
⇒ ERASE THE PIN CODE!
⇒ Enter telephone numbers and the required operating parameters in SIM memory – at least 1
telephone No. (TN1) and 1 link (LN1) should be programmed (see installer’s manual)
⇒ Insert SIM card in the GSM module applied for the ZEUS4-VD device. The unit must be
power OFF when you insert the SIM!
⇒ Connect alarm inputs and outputs to ZEUS4-VD
⇒ Connect the antenna to antenna connector
⇒ Connect device to source power supply voltage
⇒ Wait until LED3 display is turned ON (green) and LED1 (blue) starts flashing. This will be
set in around 1 minute time.
⇒ Connect the headset to Play/REC connector and record alarm messages
⇒ ZEUS4-VD unit is now ready for operate.
NOTE:
When the back-up battery 12V/1,2Ah is connected on the unit the main power supply must be
from 13,8V to 14,5V DC!
