MAXICAL
®
III 5511-229 GB/98.06/Rev. B1
52
where Q
GJ
and Q
MWh
can be seen in the following Quick table:
CCC-code (read chapter 6.1 - 6.3) Q
GJ
Q
MWh
Decimals with
[m
3
] display
000, 001, 002, 108, 109, 110, 111, 112, 115,
116, 117, 118, 119, 121, 122, 123, 124, 125,
126, 132, 133, 134, 136, 139, 156, 164, 165,
165, 300, 310 2.388.900 8.600.000 x 0,01 m
3
003 955.200 3.440.000 x 0,1 m
3
004, 006, 113, 114, 120, 127, 128, 129, 130,
131, 135, 137, 140, 141, 142, 143, 151, 152,
153, 157, 168, 301, 311 238.890 860.000 x 0,1 m
3
005, 007 95.520 344.000 x 1 m
3
008, 144, 145, 146, 147, 148, 149,
158, 169, 170, 302, 312 23.889 86.000 x 1 m
3
171, 172, 303, 313 2.388,9 8.600 x 10 m
3
Example of true Quick-figure calculation:
* MAXICAL
®
III
* Programmed for Qn 1.5 m
3
/h flow meter (CCC=119)
* Fitted in flow pipe
* 10,000 volume pulses, corresponding to 0.1 m
3
registered
* The temperature is simulated to: t
F
= 49.00°C and
t
R
= 40.00°C.
E
MJ
= m
3
x Dt x k
STUCK
= 0.1 x 9 x 4.1316 = 3.71844 [MJ]
EMJ x QGJ 3.71844 x 2,388.900
1000 1000
Quick = = = 8883
